New Technology Curves Sound and Allows Only Your Ears to Capture Audio Amidst the Crowd. Discover How This System Works and Its Possible Applications in Everyday Life
Imagine listening to music or a podcast in public without needing headphones — and without anyone else hearing it. Or participating in a private conversation in a crowded place, without the sound spreading to the surroundings. A new sound technology, developed by researchers at Penn State University, has just demonstrated that this is possible.
The researchers developed a technology capable of creating audible enclaves — localized sound pockets that are isolated from their surroundings. This means that sound becomes audible only at a specific point, without spreading through space.
With this technique, it is possible to send audio directly to a location or person, without others nearby hearing it. The discovery could transform how we interact with sound in public and private spaces.
-
Lasers fire artificial stars at 90 km altitude, overcome atmospheric turbulence with adaptive optics, and place ground telescopes closer than ever to the sharpness reserved for space.
-
Impressive discovery in England reveals a 390-million-year-old fossilized forest, surpasses an old record from the United States, and shows how primitive trees began to transform the planet.
-
390 million years later, the oldest forest ever recorded on Earth reappears fossilized in England and reveals the turning point at which primitive trees began to act as a biogeomorphic force in the transformation of the planet.
-
While automakers worldwide depend on traditional mines that evaporate 2 million liters of water per ton of lithium extracted in the driest desert on Earth, Chilean SQM, in partnership with American Lilac Solutions, will operate the first commercial-scale direct lithium extraction (DLE) plant in the Salar de Atacama, with technology that reduces water usage by 85% and recovers lithium in hours instead of months.
How Sound Behaves
Sound is produced by vibrations that propagate through the air in the form of waves. When an object moves back and forth, it compresses and decompresses the air molecules, forming these sound waves.
The frequency of these vibrations determines the pitch of the sound. Low frequencies generate bass sounds, like a bass drum. High frequencies generate treble sounds, like a whistle.
Controlling the direction of these sound waves has always been a challenge. This occurs due to diffraction, a phenomenon that causes waves to spread as they move. Diffraction is stronger in low-frequency sounds, making it even more difficult to confine sound to a specific area.
Some technologies have already been proposed to solve this problem. One example is parametric array speakers, which create directed sound beams. However, even these systems still produce sound throughout the entire path the beam travels. The sound ends up being heard by others outside the intended target.
The Science Behind Audible Enclaves
The Penn State team took a different approach. They used self-curving ultrasound beams combined with the principle of nonlinear acoustics. Ultrasound consists of waves with frequencies above 20 kHz, which are inaudible to humans. These waves are commonly used in medical examinations and industrial applications.
The innovation was using ultrasound as a carrier for audible sound. This prevented audio from being transported silently through space, making it audible only at the desired point.
The process works as follows: typically, sound waves add up linearly, creating a larger wave. But when these waves are intense or sufficient, they can interact non-linearly and generate new frequencies.
The team applied two ultrasound beams with different frequencies — which are silent by themselves — but which, when crossed, generate a new audible sound wave exactly at that intersection point.
Moreover, the researchers developed beams that curved on their own. By using acoustic metasurfaces — materials capable of manipulating the behavior of waves — they can bend the beams to navigate around obstacles and find the exact desired location.
The influence responsible for this is called difference frequency generation. For example, by combining beams of 40 kHz and 39.5 kHz, the difference of 0.5 kHz generates a new wave that is within the audible range. This sound is only heard where the two beams intersect. At all other points, it remains inaudible.
Possible Applications
The ability to direct this to a specific point has several applications. In museums, visitors could hear different audio without using headphones. In libraries, students could listen to lectures without disturbing others. In cars, passengers could listen to music while the driver receives GPS instructions.
Environments like offices or military locations could also benefit. The technology would allow for conversations in localized zones. Another possibility would be to create quiet areas in busy locations, maintaining sound humidity and improving concentration.
Despite the potential, there are still challenges. The interference caused by the nonlinear interaction of waves can affect sound quality. Additionally, the process requires high-intensity ultrasound fields, which demands a lot of energy.
Even so, the advancement represents a significant change in sound control. By allowing audio to be precisely shaped in space, the technology offers a new way to create personalized and efficient experiences. The research expands the boundaries of what is possible in the field of acoustics.
The Penn State team believes that, with further development, audible enclaves could be used on a large scale, redefining how we listen, interact, and share in our daily lives.
With information from Singularity Hub.
